Automatic Cleaning Equipment for Oak Barrels
The cleaning system is used for the internal cleaning of oak barrels and operates in a semi-automatic mode, which requires operator assistance and monitoring of the entire cleaning process. It is suitable for casks, drums and small barrels in the beer and wine industry.
Series: Oak barrel cleaning system
Rated pressure: 10-20kg
Control system: PLC/Touch screen
High pressure hose: pressure-resistant hose of 50 Bar
Cleaning object: interior of oak barrels
Overview of Oak Barrel Cleaning System
The cleaning system is used for the internal cleaning of oak barrels and operates in a semi-automatic mode, which requires operator assistance and monitoring of the entire cleaning process.
Water supply capacity – 1 multi-stage centrifugal pump with rated working pressure of 10-20 kg.
Water pump protection – anti-idling, anti-holding pressure overload, anti-overheating.
High-pressure hose – hygienic composite hose with pressure resistance of 50Bar.
Control cabinet – with PLC/touch screen/switch/inverter and other electrical components, waterproof, leakage protection, heat dissipation, and made of stainless steel.
Cleaning mechanism – flip mechanism, positioning pulleys, funnel drainage.
3D can washer–360° full coverage cleaning, high impact force, 316L material.
Optional Hand-push Automatic Ultra-high-pressure Water Washer
Specification: 95cm long * 44cm wide * 74cm high
Machine pressure: 180-250bar
Large flow rate: 11L/15L
Rated temperature: 5-50℃
Gross/Net weight: 70KG
High efficiency and durability of copper pump head.
Installation and Use Conditions of Oak Barrel Cleaning Equipment
The customer provides the energy consumption requirements of cleaning agent and power supply.
Power supply: AC380V , 50HZ, 3L+N+PE.
Industry Applications of Barrel Cleaning Equipment
It is suitable for casks, drums and small barrels in the beer and wine industry.
